| Stainless Steel Step Technical Parameters | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Model | H | D | L1 | L2 | L3 | L4 | L5 | L6 | L7 | N1 | N2 | N3 | Poles | Undercut β (°) | Other 1 | Other 2 | Other 3 | Other 4 | Remarks |
| T70-1/B | 70 | 65 | 9 | 34 | 6 | 8 | 6 | 1.5 | 3 | 2.95 | 3.5 | 3 | 13 | 26 | 42 | 105 | 25 | 128 | 64 |
| T75-3/B | 75 | 62 | 10 | 30 | 8 | 9 | 7 | 3 | 3 | 2.95 | 3.5 | 3 | 13 | 26 | 43 | 90 | 30 | 123 | 61 |
| T78/B | 78 | 56 | 10 | 26 | 7 | 8.5 | 6 | 2.5 | 3 | 2.95 | 3.5 | 3 | 13 | 26 | 43 | 90 | 30 | 123 | 55 |
| T82/B | 82.5 | 68.25 | 9 | 25.4 | 7.5 | 8.25 | 6 | 3 | 3 | 2.95 | 3.5 | 3 | 13 | 26 | 50.8 | 81 | 27 | 111 | 66.6 |
| T82-3/B | 82 | 62 | 15.88 | 30 | 8 | 8.5 | 6 | 2.5 | 3 | 2.95 | 3.5 | 3 | 13 | 26 | 50 | 114.3 | 38.1 | 156 | 61 |
| T89-1/B | 89 | 62 | 15.88 | 33.4 | 8 | 9 | 7 | 3 | 4 | 3.97 | 4.5 | 4 | 13 | 26 | 57.2 | 114.3 | 38.1 | 156 | 61 |
| T89/B | 89 | 62 | 16 | 34 | 10 | 11.1 | 7.9 | 3 | 6.4 | 6.37 | 7.14 | 6.35 | 13 | 26 | 57.2 | 114.3 | 38.1 | 156 | 61 |
| T90/B | 90 | 75 | 16 | 42 | 10 | 10 | 8 | 4 | 6.4 | 6.37 | 7.14 | 6.35 | 13 | 26 | 57.2 | 114.3 | 38.1 | 156 | 74 |
| T114/B | 114 | 89 | 16 | 38 | 9.5 | 11 | 8 | 4 | 6.4 | 6.37 | 7.14 | 6.35 | 17 | 33 | 74 | 114.3 | 38.1 | 1S6 | 88 |
| T127-1/B | 127 | 89 | 16 | 45 | 10 | 11 | 8 | 4 | 6.4 | 6.37 | 7.14 | 6.35 | 17 | 33 | 79.4 | 114.3 | 38.1 | 156 | 88 |
| T127-2/B | 127 | 89 | 16 | 51 | 10 | 15.9 | 12.7 | 5 | 6.4 | 6.37 | 7.14 | 6.35 | 17 | 33 | 79.4 | 114.3 | 38.1 | 156 | 88 |
| T140-1/B | 140 | 108 | 19 | 51 | 13 | 15.9 | 12.7 | 5 | 6.4 | 6.37 | 7.14 | 6.35 | 21 | 40 | 92.1 | 152.4 | 31.8 | 193 | 107 |
| T140-2/B | 140 | 102 | 28.6 | 51 | 17.5 | 17.5 | 14.5 | 5 | 6.4 | 6.37 | 7.14 | 6.35 | 21 | 40 | 92.1 | 152.4 | 31.8 | 193 | 101 |
| T140-3/B | 140 | 127 | 31.75 | 57 | 19 | 25.4 | 17.5 | 5 | 6.4 | 6.37 | 7.14 | 6.35 | 21 | 40 | 92.1 | 152.4 | 31.8 | 193 | 126 |
| T75 | 75 | 62 | 10 | 30 | 8 | 9 | 7 | 3 | 3 | 3 | 2.97 | 3.5 | 13 | 26 | 42 | 105 | 25 | 138 | 61 |
| T125 | 125 | 82 | 16 | 42 | 10 | 12 | 8 | 4 | 6.4 | 6.37 | 7.14 | 6.35 | 17 | 33 | 79.4 | 114.3 | 38.1 | 156 | Al |
